16 Channel Support 5MP Cameras, Dahua, XVR Digital Video Recorder

• Power Supply
  • 12V DC, 2A
• Power Consumption
  • < 10 W (HDD not included, idling)
• AHD Camera
  • 4MP, 1080P@25/30, 720P@25/30fps
• Analog Camera Input
  • 4/8/16 Channel, BNC
• Audio In/Out
  • 1/1, RCA
• Bit Rate
  • 1Kbps ~ 6144Kbps Per Channel
• CVBS Camera
  • PAL/NTSC
• Display Interface
  • 1 HDMI ,1 VGA
• Display Resolution
  • 1920×1080, 1280×1024, 1280×720, 1024×768
• HDCVI Camera
  • 4MP, 1080P@25/30fps, 720P@50/60fps, 720P@25/30fps
• IP Camera Input
  • 4+2/8+4/16+8 Channel, each channel up to 5MP
• Main Processor
  • Embedded Processor
• Operating System
  • Embedded LINUX
• OSD
  • Camera title; Time; Video loss; Camera lock; Motion detection; Recording
• Record Interval
  • 1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Postrecord: 10 ~ 300 se
• Record Mode
  • Manual; Schedule (General, Continuous); MD (Video detection: Motion Detection, Video Loss, Tampering); Alarm; Stop
• Record Rate
  • Main stream: 4M-N/1080P(1~15fps); 1080N/720P/960H/ D1/HD1/BCIF/CIF/QCIF (1~25/30fps) Sub steram: D1/CIF/QCIF(1~15fps)
• Recording Compression
  • H.264+/H.264
• Recording Resolution
  • 4M-N, 1080P, 1080N, 720P, 960H, D1, HD1, BCIF, CIF, QCIF
• TVI Camera
  • 4MP, 1080P@25/30, 720P@25/30fps
• Two-way Talk
  • Reuse audio in/out, RCA
