RIDC type, Modular Jack LS Simple 180° CAT6 F/UTP
| Category: UL Listed, TIA/EIA-568-B.2-1 / ISO 11801 |
| Meet: FCC CFR 47 Parts 68 |
| Wiring scheme: T568A/T568B |
| Current Rating: 1.5 Amps |
| DC Resistance: < 0.1 ohm max |
| Insertion Life: 750 Mating cycles |
| Pull Force: 20lbs (89N) |
| Temperature: -40°C ~ 68°C |
| Humidity: 10% ~ 90% (RH) |
| IDC accept: 22 ~ 26 AWG Solid Wire |
| Housing: High Impact Flame Retardant Plastic, UL 94V-0 Rated |
| Spring Wire: Phosphor Bronze Plated With 50 micro-inch (1.27 Microns) / Thick Gold over 100 Micro-inch (2.54 Microns) / Thick Nickel Undercoat |
| IDC Plastic: Polycarbonate or ABS, UL 94V-0 Rated |
| IDC Contact: Phosphor Bronze Plated With 100 micro- inch(2.54 microns) / Minimum Thick Tin |
| Shell (Shielded): Copper Zinc Alloy, Pre-Plated with Bright Nicke |
LS Simple™ Category 6 modular jacks are designed and manufactured to meet today’s and tomorrow’s demanding international standards.
They take into consideration the need for reliable and quick installations.
The jack is individually terminated using Insulation Displacement Connectors (IDC) giving assurance of wire connection when using a punch down tool and tool-less for Installation.
User instructions and basic wiring layout for standard configuration are included.
The LS Simple™ modular jack comes with the ability to wire to a T568A or T568B configuration and fully complies with TIA/EIA-568-B.2-1(Category 6) and ISO/IEC 11801(Class E) component performances.
