CAT6 RJ45 Plug with Boot cap LS Simple (Box)
| Approvals: UL Listed |
| Category: ANSI/TIA-568.D-2 (Category 6) |
| Wiring scheme: CFR title 47 part 68.5 and IEC 60603-7 |
| Insulation Resistance: ≥ 5000 MΩ·m |
| Contact Resistance: < 20 milli-ohm |
| Voltage: 250V AC max. at 2A |
| Insertion Life: 2000 Mating cycles |
| Pull Force: 20lbs (89N) |
| Temperature: -40°C ~ 125°C |
| Humidity: 10% ~ 90% (RH) |
| Plug housing: Transparent High-impact Polycarbonate (PC), UL 94V-2 rated |
| Contact blade: 3-prong IDC Structure, High Reliability |
| Dielectric strength: > 1000V/AC (RMS) |
LS Simple™ Modular Plug Solutions ensure the high-reliability and superior transmission performance with 50μ-inch gold coating without degradation of channel performance.
Also, They supply the benefit of easy installation for customers with cable wire and pair separator components according to plug type.
