LS Simple CAT6 RJ45 Modular Jack

• Approvals
  • UL Listed
• Category
  • ANSI/TIA-568-C.2 Category 6 (250Mhz)
• Meet
  • 47 CFR part 68
• Wiring scheme
  • T568A/T568B
• Current Rating
  • 1.5 Amps
• Insulation Resistance
  • > 500 Mega-ohm
• Contact Resistance
  • < 20 milli-ohm
• DC Resistance
  • < 0.1 ohm max
• Insertion Life
  • 750 Mating cycles
• Pull Force
  • 20lbs (89N)
• Temperature
  • -40°C ~ 68°C
• Humidity
  • 10% ~ 90% (RH)
• IDC accept
  • 23AWG ~ 26AWG (Solid wire)
• Cap
  • Polycarbonate (PC resin), UL 94V-2 rated, Transparent Black
• Housing
  • Acrylonitrile Butadiene Styrene (ABS resin) + Polycarbonate (PC resin) UL94V-0 rated
• Jack Contacts
  • Phosphor bronze flat wire, plated with 1.27μm (50μin) thick hard gold on contact area over nickel underplate
• Contact Bracket
  • Polycarbonate (PC resin), UL94V-2 rated
• PCB
  • FR4, UL 94V-0 rated
• IDC Terminals
  • Phosphor bronze, tin over nickel undercoat
• IDC Block
  • Polycarbonate (PC resin) + Glass Fiber, UL94V-2 rated
• Dielectric withstand voltage, RMS, contact to contact)
  • <1000VAC @ 60Hz
